Quick Details

  • Classification: Laboratory Heating Equipments
  • Brand Name: SuTong
  • Model Number: ST-1200RGX
  • Place of Origin: Henan, China (Mainland)
  • Product name: 1200C variable rotary quartz tube electric furnace
  • Rated Power: 3.5KW
  • Max. temperature: 1200C
  • Working temperature: 1100C
  • Furnace Tube: Dia 50mm
  • Heating Zone Length: 300mm
  • Temperature control: 30 segment programmable and PID auto control
  • Heating element: Fe-Cr-Al-Mo wire
  • Furnace structure: double shell with fan cooling

Packaging & Delivery

Packaging Details Plywood wooden case lined with plastic film and flexible foam or as customer's requirements.
Delivery Time Shipped 15 working days after the receipt of payment

CE certificated 1200C variable rotary quartz tube electric furnace

Product Description



Protech quartz tube rotary tube furnace is specially designed for calcining inorganic compound with better uniformity, esp, excellent for preparing Li-lon battery cathode materials with conductive

or protective coating on powder, such as, LiFePO3, LiMnNiO3, etc in R&D laboratory.



We bring innovative solutions to designs for experiment processing of advanced materials such asgranular, powder, or particulate aggregates in high purity and specialty atmosphere environments at temperatures up to

1200C, 1500C, 1700C, etc.



Outstanding features of 1200C rotary tube furnace

1)Rotary tube to keep uniform heating
2)Variable diameter tube to keep uniform heating
3)Programmable and PID automatic control
4)Dual zone or multra zone temperature control is possible
5)Metal key or touch panel operating interface for your option
6)Inputting protective gas or atmosphere is also possible

Concrete parts of 1200C rotary tube furnace



Specifications

Product name and model

ST-1200RGX CE certificated 1200C variable rotary quartz tube electric furnace

Furnace  chamber  size

Dia 50 x300mm

Maximum Temperature

1200C (≤3hour)

Working Temperature

400-1100C(continuously,adjustable)

Temperature control

30 steps programmable and PID automatic control

Heating Rate

0-15C/min, (suggestion ≤10C)

Temperature  accuracy

±1C

Furnace structure

Double shell with fan cooling

Heating elements

Fe-Cr-Al -Mo wire

 Furnace tilting Angle

 0-30°Variable

Working Power

AC 1-phase 110-240V 50/60Hz

Max  power

3.5 KW
